BAPI BA/10K-2-D-6-BB2 Duct Temperature Sensor

BAPI BA/10K-2-D-6-BB2 Duct Temperature Sensor
Images for general purposes only. Actual may be different than depicted.
BAPI BA/10K-2-D-6-BB2 Duct Temperature Sensor BAPI BA/10K-2-D-6-BB2 Duct Temperature Sensor

BAPI BA/10K-2-D-6-BB2 Duct Temperature Sensor

SKU: BA/10K-2-D-6"-BB2
Rating:
Quantity Price Stock
Usually Ships 3-5 Days
Usually Ships 3-5 Days
$17.64     /ea
Usually Ships 3-5 Days
0
$0.00
0
$0.00
0
BA/10K-2-D-6"-BB2
Duct Temperature Sensor

Duct units feature closed cell foam to seal the probe insertion hole, mounting tabs for easy installation and etched Teflon lead wires and double encapsulated sensors to create a watertight package. They come in probe lengths from 2" to 18". Custom probe lengths are also available. Duct Units come standard with a 2"x4" steel J-Box but are also available with no box or the new BAPI-Box Crossover enclosure.

Features:

• Probe Lengths: 2", 4", 8", 12", 18" or Custom Lengths.
Enclosure Bapi Box-2
Environmental Operating Range (Temperature) -40F to 185F (-40C to 85C)
Sensing Element 10K-2 Thermistor
Environmental Operating Range (Humidity) 0 to 100% RH non-condensing
Duct Gasket 1/4" closed cell foam (impervious to mold)
Probe Material 304 Stainless Steel 1/4" OD
Probe Length 6" Long
