| Housing Material | Glass Filled Nylon |
|---|---|
| Diaphragm | Neoprene, rolling type |
| Spring | Retract actuator shaft on loss of air pressure |
| Ambient Temperature Range | -20F to 140F (-29C to 60C) |
| Supply Air Pressure | Clean, dry, oil free air required |
| Nominal Pressure Limit | 20 PSIG (138 kPa) |
| Maximum Pressure | 30 PSIG (207 kPa) |
| Air Consumption (Position Models) | 0.017 scfm |
| Connections | Barbed fitting for 1/4" O.D. plastic tubing |
