The actuator is not provided with and does not require any limit switches, but is
electronically protected against overload. The anti-rotation strap supplied with the
actuator will prevent lateral movement.
The AMB24-SR-T N4 provides 95° of rotation and a visual indicator indicates position
of the actuator. When reaching the damper or actuator end position, the actuator
automatically stops. The gears can be manually disengaged with a button on the
actuator cover.
The AMBX24-SR-T N4 actuator uses a sensorless brushless DC motor, which is
controlled by an Application Specific Integrated Circuit (ASIC). The ASIC monitors and
controls the actuator’s rotation and provides a digital rotation sensing (DRS) function to
prevent damage to the actuator in a stall condition. Power consumption is reduced in
holding mode.
Add-on auxiliary switches or feedback potentiometers are easily fastened directly onto
the actuator body for signaling and switching functions.
