| Service | Hot and chilled water models, up to 50% glycol. Steam models up to 15 psi (both valve body and valve actuator must be rated for high temperature) |
|---|---|
| System Static Pressure Limits | 400 psi (2758 kPa) |
| Close-off | 40 PSI (276 kPa) |
| Fluid Ambient Temperature Limits | 32° to 200 °F (fluid) @ 104 °F (Ambient) (0 to 93 °C @ 40 °C) |
| Seat Leakage | ANSI class IV (0.01%) with pressure at inlet (B-port/A-port, if 3-way) |
| Body Material | Forged brass |
| Stem Material | Nickel-plated |
| Seat Material | Brass |
| Paddle Material | Buna N |
