| Type of Gases | Natural, LP and Manufactured |
|---|---|
| Flame Failure Response Time | 0.8 seconds maximum |
| Flame Sense Current | 1.0 Microamp Minimum |
| Flame Sense Voltage | 45% of Line Voltage |
| Operating Temperature | -40°F to +175°F, -40°C to +80°C |
| Gas Valve Rating | 1.5A @ 120 VAC |
| Input Power | 102 to 138 VAC, 50/60 Hz |
| Input Current Drain | 50mA @ 120 VAC, 60 Hz |
| Spark Rate | Line Frequency (50/60 Hz) |
| Moisture Resistance | Conformal coated to operate to 95% R.H. Potted to operate up to 100% R.H. |
Download Product Information:
By Feras
from Palos Heights IL
Yes, I would recommend this product to a friend or co-worker
Worked perfectly
