Accessories | Replacement Parts | ||
Part Number | Description | Part Number | Description |
0901444 | Gasket Kit | AF11S-1A | Screen Kit 100 Micron |
AF11S-1B | Screen Kit 20 Micron | KF11S-1A | Clear Plastic Sump |
AF11S-1C | Screen Kit 50 Micron | KH11S-1A | Ball Valve 2" |
AF11S-1D | Screen Kit 200 Micron | ||
FT09RS-1A | Bronze Sump | ||
MV876B1018 | Automatic Motorized Backwash Control |
Flow Capacity | 8.4 Cv |
---|---|
Maximum Ambient Temperature | 104°F (40°C) |
Body Material | Brass |
Maximum Inlet Pressure | 232 psi |
Minimum Inlet Pressure | 22 psi |
Sump Material | Clear Sump |
Screen Material | Stainless Steel |
Maximum Recommended Differential | 42 psi |
Screen Filter Rating | 100 Micron |
Tailpiece Connection Size | 3/4" Sweat and NPT Thread |
